High Frequency Automotive PCB Assembly 1.6mm 4mil PCB Electronic Circuit
Automotive PCBA High-Frequency Car Radio FM Electronics board
Product introduction:
Material: R4, (High Tg FR4, General Tg FR4, Middle Tg FR4), Lead-Free Solder Sheet, Halogen Free FR4, Ceramic Filling Material, Teflon, PI Material, BT Material, PPO, PPE, etc.
Special Process: Buried Hole, Blind Hole, Embedded Resistance, Embedded Capacity, Hybrid, Partial hybrid, Partial high density, Back drilling, and Resistance control.
Sanforized: Buried via, Blind via, Mixed Pressure, Embedded Resistance, Embedded Capacitance, Local Mixed Pressure, Local High Density, Back drill, impedance control.
| Model Number: | Leadsintec -21730FRF | Place of Origin: | Shenzhen, China |
| Base Material: | FR4 | Brand Name: | Leadsintec |
| Copper Thickness: | 1-6 OZ | Board Thickness: | 1.6MM |
| Min. Hole Size: | 0.2mm | Min. Line Width: | 4mils |
| Min. Line Spacing: | 4mils | Surface Finishing: | HASL,immersion gold,OSP |
| Product name: | PCB | Application: | Electronics Device |
| Solder mask: | Black green black red white | Service: | PCB+assembly+components |
Leadsintec is a professional PCB / PCBA manufacturer in Shenzhen China. We provide high-quality bare PCB and PCB assembly service, including components sourcing, function test, conformal coating, and complete assembly for clients all over the world.
Leadsintec provides superior service for automotive electronics, medical electronics, telecommunications, industrial control, smart home, and other industries around the world.
| PCBA Production Capabilities |
| SMT Line | 8 lines |
| Capacity: | 9 million Placements per Day |
| Maximum PCB size: | 1200x 500mm |
| Minimum chip size: | 0201 (0.2x0.1)/0603 (0.6 x 0.3mm) |
| Maximum BGA size: | 74x74mm |
| BGA ball pitch: | 1.00mm (minimum), 3.00mm (maximum) |
| BGA ball diameter: | 0.40mm (minimum), 1.00mm (maximum) |
| QFP lead pitch: | 0.38mm (minimum), 2.54mm (maximum) |
| Assembly type: | Surface mount(SMT) assembly |
| DIP assembly |
| Mixed(surface mount and through hole) technology |
| Single or double sided placement |
| Cable assembly |
| Components type: | Passive components: |
| As small as 0201 package |
| Ball Grid Arrays(BGA): |
| As small as .5mm pitch |
| Parts procurements: | Turnkey(we supply the parts) |
| Consigned(you supply the parts) |
| You supply some parts, we do the rest |
| Solder type: | Leaded/Lead-free |
| Testing: | X-Ray Inspection,AOI Testing,ICT,Flyingp Probe,In-circuit test |
Q. What service can you supply?
Leadsintec is an OEM PCB and PCBA manufacturer for 2004, we can provide turnkey solutions including RD PCB fabrication, SMT and assembly PCBA inside the enclosure, Functiontesting, and other value-added services.
Q. What file do you need to prepare if you want to get a quotation from us?
For the PCB board, you need to prepare files of Gerber file, it should including RS-274X, ODB++, DXF, PCB, PCBDOC, etc formats.
For PCBA(PCB with soldered components), except the file for PCB, you also need to prepare the BOM list (components list), Pick and Place file(text format), real sample picture or 3D PDF version file, etc.
Q. Do you have any MOQ limited?
We haven't any limits about MOQ. Sample and mass production all can support.
Q. How to keep our product information and design files secret?
We are willing to sign an NDA effect by customers side local law and promising to keep customers data at a high confidential level.
Q. How long does it take for PCB and PCBA Quote?
PCBs quotation within 2 hours can finish the PCBA depend on the components
quantity, if simple, within 6 hours can finish,once complex and more, the 12- 36 hours
can be finished.
*Please note that the following detail will speed up evaluation:
Material:
Board thickness:
Copper thickness:
Surface finish:
Solder mask color:
Silkscreen color:
Q. How about the delivery?
Normally, for sample orders, our delivery is about 5 days. For small-batch, our delivery is about 7 days.
For mass production batch, our delivery is about 10 days.
But that depends on the real condition when we get your order.
If your order is urgent please contact us directly, we will priority to deal it and do our best to give you a satisfied delivery time.
Q. How can we guarantee you receive a good quality product?
For PCB, we will use Flying Probe Test, E-test, etc.
For PCBA, we need you to offer us a method or test fixture for the function test. Before that, our inspectors will use microscope and X-ray to check the IC foot welding or bad solder, etc.
